Buggies Unlimited 48V E-Z-GO Motor 54033
$973.99
In stock
✓ Free Shipping
48V, 3 HP shunt-wound replacement motor for 2010-2022 E-Z-GO TXT, T48, Freedom TXT, and Valor golf carts.
Price shown is the online purchase price. Free shipping · 30-day return policy
BrandBuggies Unlimited
MPN / Part Number54033
OEM / OE NumberDL9-4006
Part TypeDrive motor
Product Description
Buggies Unlimited 48-volt replacement shunt-wound motor for E-Z-GO TXT, T48, Freedom TXT, and Valor golf carts built from 2010 through 2022. The motor is rated at 3 HP and 2,640 RPM and uses a 19-spline steel shaft.
This stock-grade replacement motor is identified by part number 54033 and replaces DL9-4006, 612624, and 624105. It is not for E-Z-GO DCS or PDS electric systems. A speed sensor adapter is required and sold separately.
This stock-grade replacement motor is identified by part number 54033 and replaces DL9-4006, 612624, and 624105. It is not for E-Z-GO DCS or PDS electric systems. A speed sensor adapter is required and sold separately.
Product Specifications
BrandBuggies Unlimited
ManufacturerBuggiesUnlimited
Voltage48 volts
Horsepower3 HP
Rated speed2,640 RPM
Motor typeShunt wound
Shaft spline19 spline
Dimensions9.5 in. long x 6.75 in. wide
Weight70 lb
Coil materialCopper
ManufacturerNivel
Golf Cart Compatibility
| Year | Make | Model | Power / Engine | Variant |
|---|---|---|---|---|
| 2010 | E-Z-GO | Freedom TXT | 48V | |
| 2010 | E-Z-GO | T48 | 48V | |
| 2010 | E-Z-GO | TXT | 48V | |
| 2010 | E-Z-GO | Valor | 48V | |
| 2011 | E-Z-GO | Freedom TXT | 48V | |
| 2011 | E-Z-GO | T48 | 48V | |
| 2011 | E-Z-GO | TXT | 48V | |
| 2011 | E-Z-GO | Valor | 48V | |
| 2012 | E-Z-GO | Freedom TXT | 48V | |
| 2012 | E-Z-GO | T48 | 48V | |
| 2012 | E-Z-GO | TXT | 48V | |
| 2012 | E-Z-GO | Valor | 48V | |
| 2013 | E-Z-GO | Freedom TXT | 48V | |
| 2013 | E-Z-GO | T48 | 48V | |
| 2013 | E-Z-GO | TXT | 48V | |
| 2013 | E-Z-GO | Valor | 48V | |
| 2014 | E-Z-GO | Freedom TXT | 48V | |
| 2014 | E-Z-GO | T48 | 48V | |
| 2014 | E-Z-GO | TXT | 48V | |
| 2014 | E-Z-GO | Valor | 48V | |
| 2015 | E-Z-GO | Freedom TXT | 48V | |
| 2015 | E-Z-GO | T48 | 48V | |
| 2015 | E-Z-GO | TXT | 48V | |
| 2015 | E-Z-GO | Valor | 48V | |
| 2016 | E-Z-GO | Freedom TXT | 48V | |
| 2016 | E-Z-GO | T48 | 48V | |
| 2016 | E-Z-GO | TXT | 48V | |
| 2016 | E-Z-GO | Valor | 48V | |
| 2017 | E-Z-GO | Freedom TXT | 48V | |
| 2017 | E-Z-GO | T48 | 48V | |
| 2017 | E-Z-GO | TXT | 48V | |
| 2017 | E-Z-GO | Valor | 48V | |
| 2018 | E-Z-GO | Freedom TXT | 48V | |
| 2018 | E-Z-GO | T48 | 48V | |
| 2018 | E-Z-GO | TXT | 48V | |
| 2018 | E-Z-GO | Valor | 48V | |
| 2019 | E-Z-GO | Freedom TXT | 48V | |
| 2019 | E-Z-GO | T48 | 48V | |
| 2019 | E-Z-GO | TXT | 48V | |
| 2019 | E-Z-GO | Valor | 48V | |
| 2020 | E-Z-GO | Freedom TXT | 48V | |
| 2020 | E-Z-GO | T48 | 48V | |
| 2020 | E-Z-GO | TXT | 48V | |
| 2020 | E-Z-GO | Valor | 48V | |
| 2021 | E-Z-GO | Freedom TXT | 48V | |
| 2021 | E-Z-GO | T48 | 48V | |
| 2021 | E-Z-GO | TXT | 48V | |
| 2021 | E-Z-GO | Valor | 48V | |
| 2022 | E-Z-GO | Freedom TXT | 48V | |
| 2022 | E-Z-GO | T48 | 48V | |
| 2022 | E-Z-GO | TXT | 48V | |
| 2022 | E-Z-GO | Valor | 48V |
Always compare the part number, dimensions, specifications, and compatibility details with your original part before ordering.
