10L0L 12V 200A Starter Solenoid Relay 586-105111
$40.99
In stock
✓ Free Shipping
12V DC 200A starter solenoid relay for select Yamaha G8–G20 gas golf carts, with listed cross-reference numbers for compatible replacement applications.
Price shown is the online purchase price. Free shipping · 30-day return policy
Brand10L0L
OEM / OE Number586-902
Part TypeStarter solenoid relay
Product Description
This 12V DC starter solenoid relay is designed for select Yamaha G8–G20 gas golf carts and is also identified as a glow plug relay replacement for select 7.3L Powerstroke applications. It features a 200-amp continuous contact rating, a 600-amp inrush rating, an SPNO normally open contact configuration, and an insulated four-stud design.
The solenoid is identified as White Rodgers 586-105111 and directly replaces several listed White Rodgers, Trombetta, Prestolite, and Johnson Electric numbers. The supply kit includes mounting hardware and AGS dielectric grease.
The solenoid is identified as White Rodgers 586-105111 and directly replaces several listed White Rodgers, Trombetta, Prestolite, and Johnson Electric numbers. The supply kit includes mounting hardware and AGS dielectric grease.
Product Specifications
Brand10L0L
Manufacturer10L0L
Coil voltage12V DC
Continuous contact rating200 A
Inrush rating600 A
Contact typeNormally open
ConfigurationSPNO
Connector typeScrew
Mounting typeScrew mount
Included componentsMounting hardware and AGS dielectric grease
Golf Cart Compatibility
| Year | Make | Model | Power / Engine | Variant |
|---|---|---|---|---|
| 1990 | Yamaha | G8-A | Gas | |
| 1991 | Yamaha | G8-A | Gas | |
| 1991 | Yamaha | G9-A | Gas | |
| 1992 | Yamaha | G8-A | Gas | |
| 1992 | Yamaha | G9-A | Gas | |
| 1993 | Yamaha | G11-A | Gas | |
| 1993 | Yamaha | G8-A | Gas | |
| 1993 | Yamaha | G9-A | Gas | |
| 1994 | Yamaha | G11-A | Gas | |
| 1994 | Yamaha | G8-A | Gas | |
| 1994 | Yamaha | G9-A | Gas | |
| 1995 | Yamaha | G14-A | Gas | |
| 1995 | Yamaha | G9-A | Gas | |
| 1996 | Yamaha | G14-A | Gas | |
| 1996 | Yamaha | G16-A | Gas | |
| 1997 | Ford | Excursion | 7.3L Powerstroke | |
| 1997 | Ford | F-250 | 7.3L Powerstroke | |
| 1997 | Ford | F-350 | 7.3L Powerstroke | |
| 1997 | Yamaha | G16-A | Gas | |
| 1998 | Ford | Excursion | 7.3L Powerstroke | |
| 1998 | Ford | F-250 | 7.3L Powerstroke | |
| 1998 | Ford | F-350 | 7.3L Powerstroke | |
| 1998 | Yamaha | G16-A | Gas | |
| 1999 | Ford | Excursion | 7.3L Powerstroke | |
| 1999 | Ford | F-250 | 7.3L Powerstroke | |
| 1999 | Ford | F-350 | 7.3L Powerstroke | |
| 1999 | Yamaha | G16-A | Gas | |
| 2000 | Ford | Excursion | 7.3L Powerstroke | |
| 2000 | Ford | F-250 | 7.3L Powerstroke | |
| 2000 | Ford | F-350 | 7.3L Powerstroke | |
| 2000 | Yamaha | G16-A | Gas | |
| 2000 | Yamaha | G20-A | Gas | |
| 2001 | Ford | Excursion | 7.3L Powerstroke | |
| 2001 | Ford | F-250 | 7.3L Powerstroke | |
| 2001 | Ford | F-350 | 7.3L Powerstroke | |
| 2001 | Yamaha | G16-A | Gas | |
| 2001 | Yamaha | G20-A | Gas | |
| 2002 | Ford | Excursion | 7.3L Powerstroke | |
| 2002 | Ford | F-250 | 7.3L Powerstroke | |
| 2002 | Ford | F-350 | 7.3L Powerstroke | |
| 2002 | Yamaha | G16-A | Gas | |
| 2002 | Yamaha | G20-A | Gas | |
| 2003 | Ford | Excursion | 7.3L Powerstroke | |
| 2003 | Ford | F-250 | 7.3L Powerstroke | |
| 2003 | Ford | F-350 | 7.3L Powerstroke |
Always compare the part number, dimensions, specifications, and compatibility details with your original part before ordering.
